Dell
Dell PowerEdge R7725
Enterprise-Grade AMD Dual-Socket Performance Benchmark
Qty:
1
Product Introduction
Dell PowerEdge R7725 is a 2U dual-socket rack server based on 5th Gen AMD EPYC 9005 series processors with up to 192 cores per processor. Ideal for enterprise virtualization, databases, AI inference, and big data analytics applications.
Technical Specifications
Processor
- •Two 5th Gen AMD EPYC 9005 series processors, up to 192 cores per processor
Memory
- •24 DDR5 DIMM slots, speeds up to 6400 MT/s
- •Max support 6 TB RDIMM
- •Only supports registered ECC DDR5 DIMMs
Storage Controllers
- •Internal Controller (RAID): PERC H365i DC-MHS, PERC H965i DC-MH
- •Internal Boot: Boot Optimized Storage Subsystem (BOSS-N1 DC-MHS)
- •External Controller: PERC H965e, HBA 465e
Drive Bays
- •Up to 12 3.5-inch SATA (HDD) RAID
- •Up to 24 2.5-inch NVMe RAID
- •Up to 24 2.5-inch SATA/universal drives
Power Supply
- •800 W Platinum/Titanium 100-240 VAC or 240 HVDC, hot-plug redundant
- •1100 W Platinum/Titanium 100-240 VAC or 240 HVDC, hot-plug redundant
- •1500W Titanium 100-240 VAC or 240 HVDC, hot-plug redundant
Cooling Options
- •Air cooling
- •Up to six hot-plug fans
Dimensions
- •Height — 86.8 mm (3.42 inches)
- •Width — 482.0 mm (18.98 inches)
- •Depth — 720.38 mm (28.36 inches), with bezel
Form Factor
- •2U rack server
Embedded Management
- •iDRAC9
- •iDRAC Direct
- •OpenManage Enterprise
