Dell
Dell PowerEdge R570
Simple, Scalable and Efficient Solution
Qty:
1
Product Introduction
Dell PowerEdge R570 is a 2U single-socket rack server powered by 5th Gen Intel Xeon 6 E-core processors, designed for small and medium businesses and remote offices. It offers flexible storage options, ideal for file sharing, email services, and lightweight database applications.
Technical Specifications
Processor
- •One Intel Xeon 6 E-core processor with up to 144 cores
Memory
- •16 DDR5 DIMM slots, speeds up to 6400 MT/s
- •Max support 1 TB RDIMM
- •Only supports registered ECC DDR5 DIMMs
Storage Controllers
- •Internal Controller (RAID): PERC H365i DC-MHS, PERC H965i DC-MH
- •Internal Boot: Boot Optimized Storage Subsystem (BOSS-N1 DC-MHS), M.2 adapter
- •External Controller: PERC H965e, HBA 465e
Drive Bays
- •Up to 16 3.5-inch SATA (HDD) RAID
- •Up to 8 2.5-inch SATA/universal drives
Power Supply
- •800 W Platinum/Titanium 100-240 VAC or 240 HVDC, hot-plug redundant
- •1100 W Platinum/Titanium 100-240 VAC or 240 HVDC, hot-plug redundant
Cooling Options
- •Air cooling
- •Up to six hot-plug fans
Dimensions
- •Height — 86.8 mm (3.42 inches)
- •Width — 482.0 mm (18.98 inches)
- •Depth — 802.38 mm (31.59 inches), with bezel
Form Factor
- •2U rack server
Embedded Management
- •iDRAC9
- •iDRAC Direct
- •OpenManage Enterprise
